Laserworld BeamBar 10RGB

Laserworld BeamBar 10RGB main image
The Laserworld BeamBar 10RGB is white-light laser system with ten individual apertures. Each can be controlled individually by standard DMX. Due to the analog modulation capability it is possible to create millions of colors, including white. The individual control of each beam allows for a variety of chaser, beam or fan effects. This makes the Laserworld BeamBar 10RGB ideal for use on stages, at live performances, in clubs and discotheques as well as in TV shows and show productions. In addition to the versatile DMX control, the Laserworld BeamBar 10RGB can run in stand-alone or sound-to-light mode.
  • guaranteed total output power 10 red, green and blue diode modules
  • Easy laser alignment via the front plate
  • Brightness control - analog modulation
  • DMX programmable
  • Automatic, stand-alone, and master-slave modes
    Laserworld_Beambar_10RGB_0006_beam.jpg laser image 0
    Laserworld_Beambar_10RGB_0004_beam.jpg laser image 1
    Laserworld_Beambar_10RGB_0001_beam.jpg laser image 2
    Laserworld_Beambar_10RGB_0005_beam.jpg laser image 3
    Laserworld_Beambar_10RGB_0003_beam.jpg laser image 4
    Laserworld_Beambar_10RGB_0002_beam.jpg laser image 5
    Sound-to-light modeSOUND-TO-LIGHT MODE:
    Let the beat of the music control the laser automatically
    Stand-Alone modeSTAND-ALONE MODE:
    The laser operates stand-alone and does not need and control. It plays back the content stored on the laser's mainboard.
    DMX modeDMX MODE:
    The laser can be controlled with a standard DMX controller or DMX software.
    Master-Slave modeMASTER-SLAVE MODE:
    One laser sends control commands, the other laser follows these. Works with Stand-Alone modes and Sound-to-Light modes.
Laserworld BeamBar 10RGB additional image 1
Laserworld BeamBar 10RGB additional image 2
Laserworld BeamBar 10RGB additional image 3
Laserworld BeamBar 10RGB additional image 4
This special laser effect creates fans of laser beams and can be controlled through DMX or runs in stand-alone or music mode.

The Laserworld BeamBar 10RGB is a bar with 10 single beam laser outlets, each equipped with a 120 mW / 650 nm red, 50 mW / 520 nm green and 80 mW / 450 nm blue laser diode which means it is possible to create millions of colors and white.
Each laser beam can be individually aligned through a 4-point alignment system, that can easily be accessed from the front - so no opening of the housing is necessary.

This show laser light provides an analog modulation. It means a better color fading and a much broader color hue. These facts make the Laserworld BeamBar devices ideal for all applications requiring many different color hues and color fadings.

The Laserworld BeamBar 10RGB can be controlled through DMX channels, so each diode can be controlled individually. Thus it's possible to create many different chaser, beam or fan effects.

Due to the standard DMX compatibility, the Laserworld BeamBar 10RGB can easily be integrated into an existing lighting setup.

This laser projector provides a master-slave-mode. Show lasers of the same series (slave projectors), connected via DMX to a main projector (master projector) project the same patterns like the master projector.

The Laserworld BeamBar 10RGB is a great effect for stages, live gigs and nightclubs, as well as for TV Shows and show productions.



> More details

Laserworld BeamBar 10RGB laser beam and explanatory image 5
Laserworld BeamBar 10RGB laser beam and explanatory image 6
Laserworld BeamBar 10RGB laser beam and explanatory image 7
Laserworld BeamBar 10RGB laser beam and explanatory image 8
Laserworld BeamBar 10RGB laser beam and explanatory image 9
Laserworld BeamBar 10RGB laser beam and explanatory image 10



> More details

Guaranteed Power
2'500 mW
Power Red
120 mW / 650 nm
Power Green
50 mW / 520 nm
Power Blue
80 mW / 450 nm
Beam Specifications*
ca. 3.0 mm / 0.6 mrad
Laser Source
Diode
Laser Class
3B
Operation Modes
DMX, stand-alone, Sound-to-Light, master-slave
Accessories
Interlock connector, manual, key
Power Supply
100V - 250 V AC 50/60 Hz
Power Consumption
72 W
Dimensions
1000 x 160 x 105 mm
Weight
10.5 kg
EAN / MPN
7640144996291
PDF icon Download Technical Datasheet
*Due to Advanced Optical Correction technology used in our laser systems the optical power of each colour within installed laser module(s) may slightly differ from the specification of respective laser module(s). Divergence FWHM average depending on model.
